Self Centering Chuck CNC Pipe Cutting Machine Excellent Path Quality LEDAN

1. Stable and reliable light path system and control system.
2. Double and exchange work platform save uploading time and cost.

LEDAN Fiber Lasers bring you a cost effective, low-maintenance, low operating cost,environmentally friendly solution to your organization. We deliver a machine that providesquality cutting and tolerances with small productivity loss between jobs, equating to higher returnon investments. Our fiber laser cutting machines are developed and sold based on these criteria.

Main Features:

1. Excellent path quality: Smaller laser dot and high work efficiency, high quality.
2. High cutting speed: cutting speed is 2-3 times than same power CO2 laser cutting machine.
3. Self-design rotary and plate working process combination save high cost and space.
4. Available for different diameter and length tubes.
5. Electric-drive motor in rotary device adjust speed freely. Easy-work, lower noisy, high rotary speed, high accuracy.
6. Intersecting line can be cut. Different diameter tube can be welded together. Best choice for tubular construction.
7. Low cost: Save energy and protect environment. Photoelectric conversion rate is up to 25-30%. Low electric power consumption, it is only about 20%-30% of traditional CO2 laser cutting machine.

STANDARD EQUIPMENT

1. 3 Axis (X, Y, Z)

2. CYPCUT3000 CNC control unit

3. Servo Motor

4. Auto - focus cutting head

5. Laser Source

6. Chiller Unit

7. Clean-dry air system

8. Safety Cabinet

9. Nozzle cleaning and height calibration table

OPTIONAL EQUIPMENT

1. Linear motor technology

2. IPG 0.5 kW, 1 kW, 2 kW, 3 kW, 4 kW and 6 kW laser source options

3. Nozzle changer

4. LCM (laser cut monitor) sensor for piercing control and cut-loss control

5. Automatic sheet loading system

6. Momentum Gen-3 G Force

7. Full Automatic sheet loading – unloading system (TOWER)

Fiber Laser Tube Cutting Machine Working Processes

1. Automatic Tube Bundle Loading

2. Automatic Material Alignment

3. Automatic Feeding and Rotation

4. Fiber Laser Tube Cutting

5. Unloading

Suitable for ( mm )

1. Round Tube: O.D.20 - 152

2. Square Tube: 20 x 20 – 120 x 120

3. Rectangular Tube: 20 x 20 and Max.O.D.150

4. Oval Tubes

5. L-shaped and C-shaped profiles

6. Mild Steel, Stainless Steel and Aluminum materials

Product Application

1. Applicable Fields
Applicable for high-speed cutting on various metal plates or tubes such as S/S, carbon steel, galvanized sheet,electrolytic plate, aluminum plate, steel, brass, alloy plate, rare metals and other materials;

2. Widely used
Widely used in kitchen appliance, electric control box, high-resolute device, mechanical equipment, electrical equipment, lighting, posters, auto parts, display equipment, hardware and metal processing.

LEDAN machinery, founded in 2009 ,was the first sheet metal working machines manufacturer in China.
The first production of LEDAN was a CO2 cutting machine. Nowadays LEDAN is proudly offering a wide range of products in sheet metal working industry.
LEDAN with its annually 1000 machine production capacity in its 30.000 square meter area, is the big sheet metal working machine producer company worldwide.

Welcome to visit our factory,we are located at north of Shanghai , 200km far away from Shanghai pudong air port ,by car about 2.5hours. We warmly welcome you to our factory see our machine and techincal.

Jiangsu LEDAN is a high-tech enterprise integrating R&D,manufacturing and marketing,which specializes in laser application and sheet metal automation equipment.

Main products include fiber laser cutting machine,sheet and pipe fiber laser cutting machine,pipe fiber laser cutting machine,high precision fiber laser cutting machine,robot 3D laser cutting machine and CNC press brake.

A full range of products passed through the European CE certification and access to dozens of national patents.

The laser cutting machine（Intelligent）has won the "China Red Star Design Award".
Our company is rated as the civilized unit of provincial and municipal county, national high-tech enterprise, provincial AAA credit enterprise, and provincial excellent credit management demonstration unit. We have offices all over the country .Our customers come from India, Thailand, Malaysia, Singapore, Israel, Pakistan and other countries.
Our company philosophy is quality goes beyond our brand. From R & D to design and then to production, we control every process strictly and present the best products to customers.
